JBL Cinema SB580 3.1 Channel Soundbar with Virtual Dolby Atmos and Wireless Subwoofer

Specifications

Model

CINEMA SB580

Sound system

3.1 channel

Power supply

100 - 240V AC, ~ 50/60Hz

Total speaker power output (Max @THD 1%)

440W

Soundbar output power (Max @THD 1%)

240W

Subwoofer output power (Max. @THD 1%)

200W

Soundbar transducer

3x (45 x 100) mm racetrack drivers + 3x 13mm tweeters

Subwoofer transducer

6.5” (165 mm), wireless subwoofer

Standby power

< 0.5 W

Operating temperature

0°C - 45 °C

Audio Specifications

Frequency response

40Hz-20kHz (-10dB)

Audio inputs

1 Optical, Bluetooth and USB (USB playback is available in US version. For other versions, USB is for Service only.)

Dimensions

Soundbar dimensions (W x H x D)

950 x 64 x 80 mm / 37.4’’ x 2.5’’ x 3.1’’

Subwoofer dimensions (W x H x D)

200 x 404 x 250 mm / 7.9" x 15.9" x 9.9"

Soundbar weight

2.6kg / 5.7 lbs

Subwoofer weight

5.7 kg / 12.6 lbs

Packaging dimensions (W x H x D)

1025 x 235 x 397 mm / 40.4" x 9.3" x 15.6"

Packaging Weight

10.4 kg / 22.9lbs

Control and Connection Specifications

USB port

Type A

USB rating

5V DC, 0.5A

Supporting file formats

mp3

MP3 codec

MPEG 1 Layer 2/3, MPEG 2 Layer 3, MPEG 2.5 Layer 3

MP3 sampling rate

16 - 48 kHz

Bluetooth version

5.3

Bluetooth profile

A2DP 1.3, AVRCP 1.6

Bluetooth transmitter frequency range

2400 MHz – 2483.5 MHz

Bluetooth Max. transmitting power

<10 dBm (EIRP)

Bluetooth modulation

GFSK, π/4 DQPSK, 8DPSK

2.4G wireless transmitter frequency range

2402-2481 MHz

2.4G wireless transmitter power

＜10dBm (EIRP）

2.4G wireless modulation

GFSK

Video Specifications

HDMI video input

1

HDMI video output (with Enhanced Audio Return Channel, ear)

1

HDMI HDCP version

2.3

What's in The Box

1x Soundbar

1x Wireless subwoofer

1x Remote control with batteries

1x Power cords (up to 8pcs depending on region SKUs)

1x HDMI cable

1x Wall-mount bracket kit with screws

1x Quick start guide

1x Warranty card

1x Safety sheet
