Door station/System parameters

Operation system

Embedded Linux operation system

Flash

32 MB

RAM

256 MB

Door station/Video parameters

Camera

2MP HD camera

Night vision

Low illumination IR supplement mode:3 m

Backlight compensation

Support

Digital noise reduction

Support

WDR

Support

Field of view

Horizontal: 146°, Vertical: 82°

Video Compression Standard

H.264

Motion detection

Support

Door station/Audio parameters

Audio input

Built-in omnidirectional microphone

Audio output

Built-in loudspeaker

Audio quality

Noise suppression and echo cancellation

Audio compression standard

G.711 U, G.711 A

Audio compression Rate

64 Kbps

Audio intercom

Two-way audio communication

Door station/Network parameters

Network protocol

TCP/IP, RSTP

Wired network

10/100 Mbps Ethernet

Door station/Device interfaces

Network interface

1 RJ45

RS-485

1 (1 for Hikvision's sub module communication)

Alarm input

4 (2 exit butttons and 2 door contacts by default)

Debugging port

1

Lock control

2 (2 relay, max to 30 V, 2 A)

TAMPER switch

1

Power interface

12 VDC power output (max to 12 V, 500 mA)

Door station/General

Power consumption

≤ 5 W

Working temperature

-40° C to 60° C (-40° F to 140° F)

Working humidity

10% to 95%

Dimension

Device: 98 mm × 100 mm × 42 mm (3.86" × 3.94\" × 1.65\")

Cover: 117 × 107 × 4 mm (4.61 × 4.21\" ×0.16\")

Installation Frame: 117 × 107 × 32.7mm (4.61 × 4.21\" ×1.29\")"

Installation

Surface mounting

Protection level

IP65

Indicator

0

Power supply

IEEE802.3af, standard PoE

12 VDC

Indoor station/System parameters

Operation system

Embedded Linux operation system

Memory

128 MB

Flash

32 MB

Indoor station/Display parameters

Display screen

7-inch colorful TFT screen

Display resolution

1024 × 600

Operation method

Capacitive touch screen

Indoor station/Audio parameters

Audio input

Built-in omnidirectional microphone

Audio output

Built-in loudspeaker

Audio quality

Noise suppression and echo cancellation

Audio compression standard

G.711 U, G.711 A

Audio compression Rate

64 Kbps

Indoor station/Network parameters

Wired network

10/100 Mbps self-adaptive

Wireless network

Wi-Fi 802.11 b/g/n

Protocol

TCP/IP, SIP, RTSP

RS-4851 RJ-45 10/100 Mbps self-adaptive

Indoor station/Device interfaces

RS-485

1

Alarm input

8-ch alarm inputs

Relay output

2

TF card

Max to 32 G, SD 2.0 or lower version

Indoor station/General

Power consumption

≤ 6 W

Working temperature

-10 °C to 55 °C (14 °F to 131 °F)

Working humidity

10% to 90%

Dimension

(L x W x H)200 mm × 140 mm × 23.6 mm (7.9" × 5.5" × 0.9")
