Specifications

BATTERY INFO

Capacity:

537Wh (22.4V, 24Ah)

Type:

LiFePO4 (Lithium Iron Phosphate)

Life Cycles:

2,500+ Cycles to 80% Original Capacity

Shelf-life:

Recharge to 80% Every 3-6 Months

Management System:

MPPT Controller, BMS, etc.

OUTPUT

2AC Output:

4 x 120V/20A AC Outputs, 700W In Total

Inverter Type:

Pure Sine Wave

Surge Power:

1,400W

USB-C Port:

1 x 100W Max.

USB-A Port:

4 x 5V/3A

12V DC Outlets:

1 x 12V/10A (Car Outlet)
2 x 12V/10A (DC5521)

1 Wireless Charging Pad:

1 x 15W Max.

INPUT

AC Adapter Input:

200W Max

Solar Input:

200W Max., VOC 12-28V, 8A

Car Input:

12/24V from Cigarette Lighter Port

Max Input:

400W, with AC+Solar Input

RECHARGE TIMES

AC Adapter (200W):

≈3-3.5 Hours

Solar (200W):

≈3-3.5 Hours (With prime sunshine, ideal orientation and low temperature)

12V/24V Car Outlet (98.4W/196.8W):

≈6-6.5 Hrs or 3-3.7 Hours

AC+ Solar (400W):

≈1.8~2.3 Hours (With prime sunshine, ideal orientation and low temperature)

Dual AC (400W):

≈1.8~2.3 Hours (Extra adapter is REQUIRED)

GENERAL

Weight:

16.5lbs (7.5Kg)

Dimensions (LxWxD):

10.94 x 7.87 x 7.79in (27.8 x 20 x 19.8cm)

Operating Temperature:

14-104℉ (-10-40℃)

Storage Temperature:

14-113℉ (-10-45℃)

Certifications:

UL, CEC, DOE, FCC, CA Prop 65

What's in the box

1x EB55 Power Station

1x AC Adapter & Charging Cable

1x Car Charging Cable

1x Solar Charging Cable

1x User Manual

1x Warranty Card
